High-quality OEM/ODM UEG Ceramic and Arrays Custom Design Suppliers in Chicago-Iray

As a new type of garnet-structured scintillator, UEG ceramic has a rich and adjustable lattice position, which is an innovative choice for high-precision radiation detection and empowers cutting-edge detection technology.
High-light output and low-afterglow UEG scintillation ceramic products are independently produced by iRayAM, which are used in radiological and nuclear medical equipment, industrial CT, radiation detection, vehicle container security inspection, high-energy physical detection and other fields.

Features:
• High light-output
• Low afterglow
• Fast decay time
• High density
• Low radioactive background
• Non-toxic and deliquescent
• Arrays of various pixel sizes

Technical Specification	UEG-HL	UEG-LA
Crystal System	Cubic	Cubic
Chemical Formula	GAGG:Ce	GAGG:Ce
Effective Atomic Number	54	54
Density (g/cm³)	6.5	6.44
Hardness (Mohs)	8	8
Afterglow (@20ms)	<200ppm	<50ppm
Refractive Index	1.9	1.9
Light Output (photons/Mev)	54000 ± 2000	45000 ± 1000
Energy Resolution (@663kev)	≤6%	≤6%
Decay Time (ns)	<100	<40
Emission Wavelength (nm)	553	550
Deliquescence	/	/

This document cannot be considered to be a contractual specification.

The information given herein may be modified without notice.
